CPU Model : Marvell Armada 388 88F6828 (Dual Core 1.3 GHz)
System Memory : 512 MB DDR3
Drive Bay(s) : Support 4 bays 3.5"/2.5” SATA HDD
Supported RAID Type : Synology Hybrid RAID/Basic/JBOD/RAID 0/RAID 1/RAID 5/RAID 6/RAID 10
USB 2.0 Port : 1
USB 3.0 Port : 1
Port LAN RJ-45 1GbE : 1
Power Supply Unit / Adapter : 90W
Warranty : 2 Years
| Hardware Specifications | |
| CPU | |
| CPU Model | Marvell Armada 388 88F6828 |
| CPU Architecture | 32-bit |
| CPU Frequency | Dual Core 1.3 GHz |
| Hardware Encryption Engine | |
| Memory | |
| System Memory | 512 MB DDR3 |
| Storage | |
| Drive Bay(s) | 4 |
| Compatible Drive Type* (See all supported drives) |
|
| Maximum Internal Raw Capacity | 40 TB (10 TB HDD x 4) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 16 TB |
| External Ports | |
| USB 2.0 Port | 1 |
| USB 3.0 Port | 1 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Notes |
|
| Appearance | |
| Size (Height x Width x Depth) | 184 mm x 168 mm x 230 mm |
| Weight | 2.21 kg |
| Others | |
| RJ-45 1GbE LAN Port | 1 |
| Wake on LAN/WAN | |
| System Fan | 80 mm x 80 mm x 2 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) | |
| Brightness adjustable front LED indicators | |
| Power Recovery | |
| Noise Level* | 19.1 dB(A) |
| Scheduled Power On/Off | |
| Power Supply Unit / Adapter | 90W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 21.6 W (Access) 12.75 W (HDD Hibernation) |
| British Thermal Unit | 73.75 BTU/hr (Access) 43.53 BTU/hr (System Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 2 Years |
| Notes |
|
| DSM Specifications ( See more ) | |
| Storage Management | |
| Maximum Internal Volume Number | 256 |
| Maximum iSCSI Target Number | 10 |
| Maximum iSCSI LUN | 10 |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| File Sharing Capacity | |
| Maximum Local User Accounts | 1024 |
| Maximum Local Groups | 256 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 2 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 128 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Log Center | |
| Syslog Events per Second | 100 |
| Add-on Packages (learn more about the complete add-on package list) | |
| Chat | |
| Maximum Users | 10 |
| Notes |
|
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 128 |
| Download Station | |
| Maximum Concurrent Download Tasks | 30 |
| exFAT Access (optional) | |
| HiDrive Backup | |
| Media Server | |
| DLNA Certification | |
| Office | |
| Maximum Users | 10 |
| Maximum Simultaneous Editing Users | 10 |
| Notes |
|
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 16 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* | 480 FPS @ 720p (1280x720) 240 FPS @ 1080p (1920×1080) 150 FPS @ 3M (2048x1536) 60 FPS @ 5M (2591x1944) |
| Total FPS (MJPEG)* | 240 FPS @ 720p (1280x720) 100 FPS @ 1080p (1920×1080) 60 FPS @ 3M (2048x1536) 30 FPS @ 5M (2591x1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 2 (See more) |
| VPN Server | |
| Maximum Connections | 5 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
