Kingston 3840GB SSD DC450R (Read-Centric) Enterprise DataCenter 2.5in SATA 6Gbps
| Form Factor | 2.5" |
| Interface | SATA Rev. 3.0 (6Gb/s) – With backwards compatibility to SATA Rev. 2.0 (3Gb/s) |
| Capacities | 480GB, 960GB, 1.92TB, 3.84TB, 7.68TB |
| NAND | 3D TLC |
| Self-Encrypting Drive (SED) | XTS-AES 256-bit Encryption |
| Sequential Read/Write | 480GB – 560MBs/510MBs 960GB – 560MBs/530MBs 1.92TB – 560MBs/530MBs 3.84TB – 560MBs/525MBs 7.68TB – 560MBs/504MBs |
| Steady-State 4k Read/Write | 480GB – 99,000/17,000 IOPS 960GB – 98,000/26,000 IOPS 1.92TB – 99,000/28,000 IOPS 3.84TB – 99,000/26,000 IOPS 7.68TB – 99,000/19,000 IOPS |
| Quality of Service (Latency)2,3,4 | TYP Read/Write: <500 µs / <2 ms |
| Hot-Plug Capable | Yes |
| Static and Dynamic Wear Leveling | Yes |
| Power Loss Protection (Power Caps) | No |
| Enterprise SMART tools | Reliability tracking, usage statistics, SSD life remaining, wear leveling, temperature |
| Endurance DC450R | 480GB — 285TB (0.3 DWPD/5yrs)5 960GB — 582TB (0.3 DWPD/5yrs)5 1.92TB — 1301TB (0.3 DWPD/5yrs)5 3.84TB — 2823TB (0.4 DWPD/5yrs)5 7.68TB —5063TB (0.3 DWPD/5yrs)5 |
| Power Consumption | 480GB: Idle: 1.05W, Average Read: 1.25W, Average Write: 3.03W, Max Read: 1.25W, Max Write: 4W 960GB: Idle: 1.15W, Average Read: 1.3W, Average Write: 3.18W, Max Read: 1.3W, Max Write: 4.25W 1.92TB: Idle: 1.22W, Average Read: 1.42W, Average Write: 3.44W, Max Read: 1.42W, Max Write: 4.5W 3.84TB: Idle: 1.3W, Average Read: 1.48W, Average Write: 3.93W, Max Read: 1.48W, Max Write: 5.5W 7.68TB: Idle: 1.38W Average Read: 1.5W Average Write: 4W Max Read: 1.5W Max Write: 5.5W |
| Storage temperature | -40°C ~ 85°C |
| Operating temperature | 0°C ~ 70°C |
| Dimensions | 69.9mm x 100mm x 7mm |
| Weight | 92.34g |
| Vibration operating | 2.17G Peak (7–800Hz) |
| Vibration non-operating | 20G Peak (10–2000Hz) |
| MTBF | 2 million hours |
| Warranty/support6 | Limited 5-year warranty with free technical support |
