CPU: Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
System Memory: 8 GB RAM |
Flash Memory: 4GB (Dual boot OS protection) |
Drive Bay: 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
M.2 Slot : 2 x M.2 2280 PCIe Gen 3 x1 slots |
2.5 Gigabit Ethernet Port (2.5G/1G/100M):2 (2.5G/1G/100M/10M) |
Power Supply: 100W PSU, 100-240V |
Form Factor: 1U Short Depth Rackmount |
Warranty: 3 Years |
CPU | Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
CPU Architecture | 64-bit x86 |
Graphic Processors | Intel® UHD Graphics |
Floating Point Unit | |
Encryption Engine | (AES-NI) |
Hardware-accelerated Transcoding | |
System Memory | 8 GB RAM |
Maximum Memory | 8 GB |
Flash Memory | 4GB (Dual boot OS protection) |
Drive Bay | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot-swappable | |
M.2 Slot | 2 x M.2 2280 PCIe Gen 3 x1 slots
Compatible with NVMe SSD PCIe Gen 3 and above. Please refer to https://www.qnap.com/compatibility/ for compatibility.
|
SSD Cache Acceleration Support | |
2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
Wake on LAN (WOL) | |
Jumbo Frame | |
USB 2.0 port | 2 |
USB 3.2 Gen 2 (10Gbps) Port | 2 x Type A USB 3.2 Gen 2 |
HDMI™ Output | 1, HDMI™ 1.4b |
Form Factor | 1U Short Depth Rackmount |
LED Indicators | Power/Status, LAN, USB, HDD1-4, M.2 SSD 1-2 |
Buttons | Power, Reset |
Dimensions (HxWxD) | 1.7 × 16.93 × 11.5 inch |
Weight (Net) | 10.93 lbs |
Weight (Gross) | 13.01 lbs |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | 100W PSU, 100-240V |
Power Consumption: HDD Sleep Mode | 21.105 W |
Power Consumption: Operating Mode, Typical | 35.297 W
Tested with drives fully populated.
|
Fan | 3 x 40mm |
System Warning | Buzzer |
Standard Warranty | 3 |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 1500 |
