CPU: Intel Xeon E-2124 quad-core 3.3 GHz processor (burst up to 4.3 GHz)
System Memory: 8GB UDIMM DDR4 ECC (2 x 4GB)
Memory Slot: 4 x Long-DIMM DDR4, Max 128 GB (4 x 32 GB)
Flash Memory: 5GB (Dual boot OS protection)
Drive Bay: 4 x 3.5-inch + 5 x 2.5-inch SATA 6Gb/s, 3Gb/s
Gigabit Ethernet Port (RJ45) : 2
10 Gigabit Ethernet Port): 2 x 10GbE SFP+ SmartNIC port
Power Supply: 250W, 100-240V
Form Factor: 1U Rackmount
Warranty: 3 Years
CPU | Intel® Xeon® E-2124 quad-core 3.3 GHz processor (burst up to 4.3 GHz) |
CPU Architecture | 64-bit x86 |
Floating Point Unit | |
Encryption Engine | (AES-NI) |
System Memory | 8 GB UDIMM DDR4 ECC (2 x 4GB) |
Maximum Memory | 128 GB (4 x 32 GB) |
Memory Slot | 4 x Long-DIMM DDR4 |
Flash Memory | 5GB (Dual boot OS protection) |
Drive Bay | 4 x 3.5-inch + 5 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives |
Hot-swappable | |
SSD Cache Acceleration Support | |
Gigabit Ethernet Port (RJ45) | 2 |
10 Gigabit Ethernet Port | 2 x 10GbE SFP+ SmartNIC port |
Wake on LAN (WOL) | |
Jumbo Frame | |
PCIe Slot | 1 Slot 1: PCIe Gen 3 x16 |
USB 3.2 Gen 1 port | 4 |
USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-C USB 3.2 Gen 2 10Gbps |
Form Factor | 1U Rackmount |
LED Indicators | HDD 1-4, SSD 1-5, Status, LAN |
Buttons | Power, Reset |
Dimensions (HxWxD) | 43.3 × 482.6 × 484.15 mm |
Weight (Net) | 7.48 kg |
Operating temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | 250W, 100-240V |
Power Consumption: Operating Mode, Typical | 74.35 W
Tested with drives fully populated.
|
Fan | System fan: 3 x 40mm, 12VDC |
System Warning | Buzzer |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 10000 |
