| CPU: AMD Ryzen™ 5 7000 series 6-core/12-thread processor, burst up to 5.1 GHz |
| System Memory: 32 GB UDIMM DDR5 (1x 32 GB) |
| Memory Slot: 4 x UDIMM DDR5 Support optional ECC memory |
| Flash Memory: 5GB (Dual boot OS protection) |
| Drive Bay: 30 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M): 2 (2.5G/1G/100M/10M) 10 Gigabit Ethernet Port: 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Power Supply: 550W(x2), 100-240V |
| Form Factor: 2U Rackmount |
| Warranty: 5 Years |
| CPU | AMD Ryzen™ 5 7000 series 6-core/12-thread processor, burst up to 5.1 GHz
AMD Radeon Graphics
|
| CPU Architecture | 64-bit x86 |
| Floating Point Unit | |
| Encryption Engine | (AES-NI) |
| Hardware-accelerated Transcoding | |
| System Memory | 32 GB UDIMM DDR5 (1x 32 GB) |
| Maximum Memory | 192 GB (4 x 48 GB) |
| Memory Slot | 4 x UDIMM DDR5 Support optional ECC memory |
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 30 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 2.5-inch SATA solid state drives |
| Hot-swappable | |
| SSD Cache Acceleration Support | |
| GPU pass-through | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Wake on LAN (WOL) | |
| Jumbo Frame | |
| PCIe Slot | 3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4* Slot 3: Gen4 x 4 *Slot 2 provides the width of PCIe Gen4 x8 when Slot 1 is not in use, and provides the width of PCIe Gen4 x4 when Slot 1 is in use.
|
| USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-A USB 3.2 Gen 2 10Gbps |
| Form Factor | 2U Rackmount |
| LED Indicators | Power Status, SSD 1-30, Status, LAN, storage expansion port status |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 3.48 × 18.98 × 21.64 inch
Excludes ear hook and the protruding part of the Power Supply Unit.
|
| Weight (Net) | 28.06 lbs |
| Weight (Gross) | 41.2 lbs |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical | 380.23 W
Tested with drives fully populated.
|
| Fan | System fan: 3 x 60mm, 12VDC |
| System Warning | Buzzer |
| Standard Warranty | 5 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 5000 |
