Applied Models:
FS3017*
RS18017xs+
Note:Connecting to a Synology FlashStation FS3017 requires the optional FS3017 Expansion Card (FXC17) to be installed on the host device.
FS3017 Expansion Card is sold separately.
Drive Bay(s): 12
Power Supply Unit / Adapter: 2 x 500W
| Hardware Specifications | |
| Applied Models |
|
| Note | Connecting to a Synology FlashStation FS3017 requires the optional FS3017 Expansion Card (FXC17) to be installed on the host device. FS3017 Expansion Card is sold separately. |
| Storage | |
| Drive Bay(s) | 12 |
| Compatible Drive Type* (See all supported drives) |
|
| Maximum Internal Raw Capacity | 120 TB (10 TB HDD x 12) (Capacity may vary by RAID types) |
| Hot Swappable Drive | |
| RAID Management through Synology DSM | |
| External Ports | |
| SAS IN-port | 1 |
| SAS OUT-port | 1 |
| Appearance | |
| Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm |
| Weight | 18 kg |
| Power | |
| Power Supply Unit / Adapter | 2 x 500W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 132.7 W (Access) 89.3 W (HDD Hibernation) |
| British Thermal Unit | 452.79 BTU/hr (Access) 304.7 BTU/hr (HDD Hibernation) |
| Redundant Power Supply (for RP model) | |
| Temperature | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Others | |
| System Fan | 60 mm x 60 mm x 4 pcs |
| Easy Replacement System Fan | |
| Noise Level* | 60.9 dB(A) |
| Certification |
|
| Warranty | 5 Years |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories | Synology RKS1317 - Rail Kit Sliding |
